Product Description
This Part is a 48 or 56 Frame Face Plate for a Jacuzzi or Sundance Intertek LX Brand Pump Wet End only this face plate uses fine thread bleeder plugs be sure to compare your old plugs to the pictures. This face has a flange inside that will not work with a wear ring.. It is about 7 3/4"" across the face, it measures about 2 1/4" from the bottom to the top width, it also measures 3" across the threads. The Suction and Pressure side thread fittings are called 2" x 2" but measure 3" from the edge of the thread to the edge of the thread.
NOTE: This Face will not fit the standard WUA100-400 Wet Ends!
For the other parts for this face see the links below:
Face O-Ring Intertek LX Pump Jacuzzi Premium & Sundance fits 48 or 56 Frame Replacement Face O-Ring
Barbed Bleeder Plug Intertek LX 48 or 56 Frame Wet End Fine Threads Jacuzzi® or Sundance®
Jacuzzi Premium & Sundance 2 5/8" Center to Center O-Ring Hot Tub Spa 2" Pump Union ORing
