Product Description
Vico Ultimax 56 Frame side discharge pump assembly by Balboa Water Group in 3 HP, 230 Volt, 2 speed, sometimes referred to as the "Niagra". This line of spa pumps are top of the line and provide great flow rates for a powerful jet massage. This wetend has two barbed ports that can be drilled out of needed in your application. Common to find on Cal Spas, Icon, Ion, Leisure Bay Spas and Coleman Spas to name a few.
This pump at times has been marketed as a 4 horsepower. If your Ultimax pump has a 12.0 amp motor this is the correct pump for you.
Can be use to replace the discontinued Vico Bigfoot with minor replumb on suction fitting.
| Motor Voltage | 230v |
| Speed | 2 Speed (2-Spd) |
| Motor Amperage/Wattage | 12.0A/3.5A |
| Horsepower | 3.0hp |
| Manufacturer | Vico/Balboa |
| Pump Model | Ultimax |
| Suction Pipe Size | 2" (3" thread diameter) |
| Suction Connection Type | Male Buttress Thread (mbt) |
| Suction Style | Center |
| Discharge Pipe Size | 2" (3" thread diameter) |
| Discharge Connection Type | Male Buttress Thread (mbt) |
| Discharge Style | Side |
| Motor Frame | 56 Frame Thru-Bolt |
IMPORTANT MOTOR VARIATION NOTICE
Due to ongoing changes in the hot tub pump industry since COVID, motor appearance and configuration may vary, even when the part number is the same. While the pump wet end will be correct, the motor may differ in areas such as capacitor location, labeling, or housing.
If you have a specific motor requirement (clearance, capacitor position, orientation, etc.), you must contact us before ordering so we can verify availability. Do not order first and contact us after delivery due to appearance differences.
Motor variations are outside of our control and may change week to week. Appearance differences do not constitute an incorrect item if specifications are met.
