Product Description
This part is a Control System, Balboa, BP Series, BP2000G1, 5.5KW, 800 INC, BP2X, WiFi Capable
This is a New Updated Website with better shipping prices and more products.
If you are previous customer to this site all of your information
is still in the site but you will need to do a password reset using your email..
When we Migrated over the Information to the new site no Passwords Migrated.
Old and New Customers we have now Lowered the shipping rates on this site to
FREE SHIPPING IN THE USA ON PARTS ORDERS OVER 75.00 Except
Hawaii and Alaska
If you place an Order In Hawaii or Alaska and don't pay shipping on heavy items we
will contact you for shipping payment.
Note: We Do Not Ship Heavier Items like Pumps outside of the USA..
This part is a Control System, Balboa, BP Series, BP2000G1, 5.5KW, 800 INC, BP2X, WiFi Capable
Unparalleled system reliability and innovative engineering. Utilizing higher resistant materials, the BP2000/2100 operates: 2-speed primary pump, (2) 2-speed secondary pumps, Circulation pump, Blower, Ozone and Lights. The BP2000/2100 control system is designed using Balboa's patented M8 smart temperature and flow sensor technology. Smoothly integrates with all of Balboa's accessories such as ControlMySpa™, bba™, and Balboa's various topside panels, including state-of-the-art touchscreen panels.
Features:
*If installing a 24 hour circulation pump, it must have no less than a 23 GPM flow. Laing, Grundfos or Waterway Tiny Might pumps do not perform at this rate and cannot be used.
Standard Features And Operations | ||
---|---|---|
Pump 1 Circuit | 120V or 240V | 1 or 2 Speed Pump |
Pump 2 Circuit | 120V or 240V | 1 or 2 Speed Pump |
Pump 3 or Blower Circuit* | 120V or 240V | 1 or 2 Speed Pump or 1 Speed Blower |
Circ Pump Circuit | 120V or 240V | Circulation (Requires 23 GPM) |
Ozone Circuit | 120V or 240V | Controlled By Filter Cycle |
AV Circuit | 120V or 240V | For Stereo/Video |
Light Circuit | 12V | On/Off |
Topside Control | - | Not Included |
Titanium Heater (800INC) | 120V or 240V | 5.5 KW (240V) - 1.0KW (120V) |
Temperature Sensor | Heater Mount | Auto Reset |
Overheat Sensor | Heater Mount | Auto Reset |
Wi-Fi Ready | Requires Module 50350 | |
Warranty | 1 Year |
*Can do one or the other but not both
