Product Description
NOTE: This Complete Heater Assembly has just come available I have them in stock...
This part is a 4.0KW Spa Heater Complete Assembly found in a Jacuzzi Whirlpool Control System includes the Element, Pressure Switch, new Titanium Element and Hi Limit Switch. These Heaters are usually found in Jacuzzi Whirlpool, Gatsby, Imperial, White Spring, Echo, Blue Ridge, Swift River, LBI or Leisure Bay Industries and others.
For the 5.5KW Version Click Here: Jacuzzi Whirlpool Spa Hot Tub Heater Kit for 5.5kw Gatsby Imperial Blue Ridge LBI
Note: When testing this heater if it trips the breaker simply unplug it and if the breaker stays on plug back in and if it trips this heater is the cause if it is not a breaker trip issue then measure between the two terminals with an Ohm meter it should measure about 14.5K ohms. If it measures 0K it is open. If it is not tripping the breaker and doesn't measure open then the heater is not bad look for other issues that cause no heat Like a Pressure Switch, Stopped up filter, No water movement, Open circuit on board etc….. On this particular heater the pressure switch is included and it can cause a no heat condition and can be purchased separately in our store.
Heater Application:Gatsby Spas
Heater Voltage:230V
Heater Length:7-1/2"
Heater Type:Low Flow
Heater Wattage:4.0kW
Heater Feature:Titanium Element
Heater Feature:w/Hi Limit
Heater Feature:w/Pressure Switch
