Product Description
This part is a Balboa Circuit board for an EL2000 Mach 3 system it is a new board and can be found under several different numbers.. The compatible topside would be a MOLEX system plug not a phone plug..
Circuit Board Application Balboa Water Group
Circuit Board Model EL2000 Mach 3
Circuit Board Type New
Manufacturers Part Number 53RAC-05
Please be aware: Chip # TS2000R1A corresponds to the Balboa EL2000 Mach 2 circuit board while TS2000R2A corresponds to the Balboa EL2000 Mach 3 circuit board. The difference is the position of the mounting holes.
This board replaces: 33-0029-K , 33-53834-K , 52680 , 53834-04 , 9710-109 , EL2000_Mach3 , EL2000M3R2D , EL2000R1B , TS2000R2A
This circuit board will replace Thermo Spa 55000-02, 55000-03 - 55001 - TS2000R2A, TS2000R2B & TS2000R2C
THIS BOARD INSTALLS IN A PLASTIC BOX and Will not work in the Metal box..
