Product Description
This is a complete retro-fit kit that includes a new spa pack with 5.5 KW heater, LED digital spa side control with programmable functions, and equipment cords and features full automation for bringing your spa 'up-to-date'.
The ACC Smartouch Modpack 1000 is a 120/240 volt smart digital controller that operates a single 2 speed pump, single speed blower (or 2nd pump), ozone and a 12 volt lighting (see below for fiber optic option). What makes this control unique is that is utilizes an off board contactor for the heater which prevents the need to replace your circuit board when the heater relay fails. Heater relays are the most common failure on digital control systems and only your contactor needs to be changed in the even of failure.
The 6 button topside control panel measures 5-1/2" x 2-1/2" on the outside and requires a 4-3/4" x 1-3/4" hole size
If you need a spa pack with the same support but with a versatile slide heater click here!
If you need a blackout plate click here.. Adapter Blackout Plate, Hydro-Quip 8-1/2" x 3-1/2". For Eco-401 or Balboa E4 Duplex Topside
If you need your ModPack to run Fiber Optic add this option.. Retrofit MODPACK Fiber Optic Option This is in Addition to a New Modpack purchase
- Pump One circuit, two speeds, 220V, 12A Max
- Pump Two circuit, up to 2 speeds (When activated), 220V, 12A Max
- Blower circuit, 110/220V, 7A Max
- Circ Pump circuit, 110/220V, 4A Max (24Hr when activated, Requires 25 GPM)
- Ozone circuit, 110/220V, 1A Max
- 12V 12W Light circuit
- 1.4/5.5KW, 120/240V Flo-Thru heater, stationary
- 48" amp motor, blower, and ozone cords
- Topside Panel Included
- UL and ETL Listed
- Freeze protection
- High-limit protection
- Filtration mode
- Economy Mode
